Stainless Steel Braid Cover Smooth PTFE Tube w/ Threaded Pipe Fitting

Teflon core

Stainless steel smooth bore ptfe braided hose

Chemical teflon hose is widely used for most kinds of chemical liquids conveyance in oil extraction, car brake system, steel and plastic making industry and other industries. It is also used to convey oils, gas and fuel. It is composed of two parts: tube and cover. Tube is made from teflon (PTFE), making hose resistant to corrosion caused by chemical liquids and high temperature. And the hose has excellent flexibility and non-adhesive surface. Cover is made from 304 or 316 stainless steel braided, making hose have high strength and suitable for high pressure and harsh working environments. Besides, the braided stainless steel cover makes hose have longer service life.

  • Temperature Range: -65° to 450° F

  • Material: PTFE with 304 Stainless Steel Braid, SS316 is available

  • Both fittings flared or BSPP/BSPT/NPT/JIC etc

This hose is PTFE with a stainless steel braid for more chemical resistance and better strength than other chemical hose. Stainless steel fittings have very good corrosion resistance.

Polytetrafluoroethylene (PTFE) is an engineered fluoropolymer, and has numerous applications. It is a thermoplastic polymer and has exceptional resistance to a wide variety of chemicals. PTFE Hose has increased resistance to vibration and flexing, and is a considerable saving in replacement cost, when used to replace other material hoses.


It has excellent shelf life, practically unlimited. Used more commonly for sanitary applications. Unlike other non metal hose, PTFE Hose will not impart taste.It has excellent chemical resistance, non contamination properties and resists deterioration. Provides good flexing for longer lengths of the hose, and is used for applications which require medium pressure. Silicon sleeve or Rubber hose covering can be used externally for protection against external harsh environments.


Hose Inner Diameter : 1/4", 3/8", 1/2", 5/8", 3/4", 1", 1.5", 2", 3"

Hose Length : Available as per your specification.

Design : Plain tube, without any corrugations, with outer Stainless Steel Braiding for Pressure resistance

Bend Radius, Flexing : View Bend radius, flexing data

Hose Material : PTFE ( Polytetrafluoroethylene ) Hose

Smooth bore type

ptfe braided hose
