Tri Clamp Lever Style Sample Valves with Coil SS304 Stainless

Sampling valves are used in piping systems or on tanks for sampling. It can also be assembled at the bottom of the tank or pipeline for residue drain.

Stainless steel sample faucet for brewing tanks.

Retail price-USD62/pc.

please email me for discount if quantity over 30pcs.

With shuangzhan machinery sampling valves you can take representative samples in a variety of hygienic processes including food, beverage, biopharm. These reliable aspetic valves provide the high accuracy, exceptional reproducibility and excellent reliability required for high quality, cost-effective sampling. The clear and comfortable designed handle ensures exceptional control and convenience during operation.


  • Design ensures hygienic and contamination-free sampling

  • Easy to operate

  • Highly reliable operation (rated to 10 bar) and three year warranty for all metal parts, provides spare gaskets.

  • Safe sampling through features such as non-return, quick couplings, pressure relief valve for steam and more

Materials: SS304
End: 1.5" tri clamp end with 10mm hose barb
Diaphragm: food grade FKM

samplecoilvalve (2)
