Flanged Electric Butterfly Valve
Threaded Electric Butterfly Valve
Tri-clamped Electric Butterfly Valve
Welded Electric Butterfly Valve
Protection degree: IP-67.
Environment temperature: -2°C ~ 60°C (other temperature can be custom made).
Installment angle: any angle.
Material of body: aluminum alloy diecasting.
Features optional: torque than the protection, heated dehumidifier, over-heat protection.
Hand operation: by detachable hexagon.
Spacing: electrically: completely close and open limit switch.
Manually: link stopper.
Input signal: 4-20mA.DC, 1-5V.DC, 0-10V.DC (other signals can be chose before leaving factory).
Output signal: 4-20m A.DC, 0-10V.DC (other signals can be chose before leaving factory).
Voltage: AC.24V 110V 220V 380V DC.24V Frequency: 50HZ,60 HZ.
Type of control: on-off indicator light, passive contact point, opening position, intelligent control
Switching time(S): 9,10,13,15,20,25,30,50,60,1000.
Forged valve body – stainless steel T304, T316L.
Simple and robust design.
Low pressure losing.
Renewable design of valve body.
Every connection of flanged, butt welded, tri-clamp, threaded etc.
Electric actuator brand on request.
